Hydraulic Parts Technical Specifications

• • The pump is 40cm³ variable flow rate BERARMA brand.
• • A 180 Lt oil filter is used in our hydraulic tank.
• • A 4 Lt hydraulic battery is used in our hydraulic system.
• • 4/2 and 4/3 position valves are used in our hydraulic systems.
• • The felts used in our drum and unit groups are KASTAŞ brand and NUTRING felts are used.
• • Hydraulic hoses are between 180- 225 pressure.

Electronic Parts Technical Specifications

• • Our machine works with 380V AC.
• • A 10'' Touchscreen KINCO screen is used in our automation system.
• • M12 sensors and sensor cables are used in our automation system.
• • Our machine is PLC controlled and DELTA brand PLC is used.
• • ALLEN-BRADLEY drivers are used in our automation system.
• • Switchgear materials used in our automation system are SCHNEIDER brand.

Unit Group Features

• • Turning, Opening Head, Guide Units: Unit spindle forged cementa Mn16 Cr5 material is used.
• • Unit spindle bearings are tapered and FAG and SKF brands are used.
• • Unit spindle, bronchus and rear bearings are FAG and SKF brands.
• • Our unit main body is made of GG26 cast iron material and the turning process After it is finished, it is ground precisely.
• • The opening head mechanism uses GG26 cast iron material.
• • The motors used in our unit groups are between 0.75 KW and 5.5 KW, depending on the product requirement
It is changing.
• • Our units rotate between 300 and 6000 RPM, either fixed or variable.
• • The stroke of our unit groups can go up to 110 mm.
• • The stroke of our long unit groups can be up to 200 mm.
• • The stroke of our sliding unit groups is 40 mm.
• • Precise speed settings are used in our unit groups.
• • Our unit groups operate at pressures between 40 and 60 BAR.
